| Content | Standards | |
| Nominal capacity @4.0~2.0V | 10.0 | Ah |
| Rated voltage | 3.05 | V |
| ACinternal resistance | ≤3 | mΩ |
| DC internal resistance | ≤10 | mΩ |
| Battery weight | 270±5 | g |
| Battery size | Diameter:φ33.2±0.2 Height:140±0.3 |
mm |
| Charge cut-off voltage | 3.95 4.0 3.9 3.8 |
V |
| Charge cut-off current | 500(0.05C) 1000(0.1C) |
mA |
| Discharge cut-off voltage | 2.0 | V |
| Standard continuous charge current |
5000 | mA |
| Maximum continuous charge current |
30000 | mA |
| Standard continuous discharge current |
5000 | mA |
| Maximum continuous discharge current |
30000 | mA |
| Energy density | ≥110 | Wh/kg |
